Radiator Dimensions

397 x 120 x 27 mm (L x W x H)

Radiator Material

Aluminum

PUMP

Dimensions

Φ67*48.5 mm

Rating Voltage

DC 12 V

Minimum Startup Voltage

‰¥5.0V

Fan Speed

2800 ±10% RPM

Rated Current

0.25 ±20% A

Consumed Power

3.0 W

Flow rate

‰¥1300 mL/min

Water Pressure

1.4 m

Operation Temperature

-10 °C ~ +60 °C

Noise Level

‰¤28 dB(A)

Lifespan

40,000 hours

Connector

PUMP: 3-pin | LED: 3-pin

FAN

Fan Type

PWM Fan

Dimensions

120*120*25 mm

Bearing Type

Hydraulic Bearing

LED Type

Addressable RGB

Fan Speed

800 ±200~1800 ±10% RPM

Airflow

71.5 CFM(max.)

Air Pressure

2.45 mmH ‚‚O(max.)

Fan Noise Level

31 dB(A)

Lifespan

40,000 hours

Connector

PH 2.0 7-pin (PWM+ARGB)

Rated Voltage

FAN: DC 12 V | LED: DC 5 V

Operation Voltage

FAN: DC 10.8-13.2 V | LED: DC 4.5-5.5 V

Rated Current

FAN : 0.20-0.25 A | LED : 0.32 A

Socket Compatibility CPU

Intel: LGA 115X/1200/1700/20XX/1851

AMD: AM3/AM4/AM5/TR4

TDP

‰¤ 280W
