Output
Max Configurable Power (Watts)	900 Watts / 1.6kVA
Output Frequency (sync to mains)	50/60 Hz +/- 1 Hz Sync to mains
Topology	Line interactive
Waveform type	Stepped approximation to a sinewave
Transfer Time	6 ms typical : 10 ms maximum
Output Connections (Battery Backup)	4
Input
Input frequency	50/60 Hz +/- 5 Hz Auto-sensing
Input voltage range for main operations	140 - 300V
Number of Power Cords	1
Input Power Factor at Full Load	0.56
Batteries & Runtime
Battery type	Lead‑acid battery
Typical recharge time	8 hours
Nominal Battery Voltage	24 V
Expected Battery Life (years)	3 – 5
Battery Volt‑Amp‑Hour Capacity	168
Communications & Management
Control panel	LED Status display (online / on battery)
Audible Alarm	Alarm when on battery; distinctive low‑battery alarm
Surge Protection & Filtering
Surge energy rating	273 Joules
Data Line Protection	RJ45 10/100/1000 Base‑T Ethernet protection
Physical
Maximum Height	190 mm (19.0 cm)
Maximum Width	140 mm (14.0 cm)
Maximum Depth	390 mm (39.0 cm)
Net Weight	10.3 kg
Colour	Black
SCC Codes	10731304410772
Environmental
Operating Temperature	0 – 40 °C
Operating Relative Humidity	0 – 95 % (non‑condensing)
Operating Elevation	0 – 3000 m
Audible noise @ 1 m	40 dBA
Protection Class	IP20
Conformance
Approvals	CB, CE, EN/IEC 62040‑1, EN/IEC 62040‑2, RCM
Standard warranty	2 years repair or replace
Sustainable Offer Status
RoHS	Compliant
