SPECIFICATIONS:

CPU	AMD Socket AM5 for AMD Ryzen ™ 9000 & 8000 & 7000 Series Desktop Processors* * Refer to https://www.asus.com/support/downloadcenter/ for CPU support list.
Chipset	AMD B850 Chipset
Memory	4 x DIMM slots, max. 256GB, DDR5 Supports up to 8000+MT/s(OC) with Ryzen ™ 9000 & 8000 & 7000 Series Processors, ECC and NonECC Unbuffered DIMM* Dual channel memory architecture Supports AMD Extended Profiles for Overclocking (EXPO ™) ASUS Enhanced Memory Profile (AEMP) * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/downloadcenter/. Adjustments will be made based on the specifications of massproduced memory products available on the market. * NonECC, unbuffered DDR5 memory supports OnDie ECC function.
Graphics	1 x DisplayPort 1 x HDMI ™ port* * Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications. Supports max. 8K@30Hz as specified in DisplayPort 1.4. * Supports 4K@60Hz as specified in HDMI 2.1.
Expansion Slots	AMD Ryzen ™ 9000 & 7000 Series Desktop Processors* 1 x PCIe 5.0 x16 slot (supports x16 mode) AMD Ryzen ™ 8000 Series Desktop Processors 1 x PCIe 4.0 x16 slot (supports x8/x4 mode)** AMD B850 Chipset 1 x PCIe 4.0 x16 slot (supports x1 mode) 1 x PCIe 4.0 x1 slot * Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/). ** Specifications vary by CPU types. To ensure compatibility of the device installed, please refer to https://www.asus.com/support/downloadcenter/ for the list of supported peripherals.
Storage	Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports AMD Ryzen ™ 9000 & 7000 Series Desktop Processors M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) AMD Ryzen ™ 8000 Series Desktop Processors M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4/x2 mode)* AMD B850 Chipset M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports * Specifications vary by CPU types. AMD RAIDXpert2 Technology Ryzen ™ 9000 Series Processors: RAID 0/1/5/10 Ryzen ™ 8000 Series Processors: RAID 0/1 Ryzen ™ 7000 Series Processors: RAID 0/1/10
Ethernet	1 x Realtek 2.5Gb Ethernet TUF LANGuard
Wireless & Bluetooth	WiFi 6E 2x2 WiFi 6E (802.11ax) Supports 2.4/5/6GHz frequency band* Bluetooth ® v5.3** * WiFi 6E 6GHz regulatory may vary between countries, supported only in Windows 11 or later. ** The Bluetooth ® version may vary, please refer to the WiFi module manufacturer's website for the latest specifications.
USB	Rear USB (Total 8 ports) 2 x USB 10Gbps ports (1 x TypeA + 1 x USB TypeC ®) 3 x USB 5Gbps ports (3 x TypeA) 3 x USB 2.0 ports (3 x TypeA) Front USB (Total 7 ports) 1 x USB 20Gbps connector (supports USB TypeC ®) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports * USB TypeC ® power delivery output: max. 5V/3A.
Audio	Realtek 7.1 Surround Sound High Definition Audio CODEC* Supports: Jackdetection, Multistreaming, Front Panel Jackretasking Supports up to 24Bit/192 kHz playback Audio Features Audio Shielding Premium audio capacitors Dedicated audio PCB layers Audio cover * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Back Panel I/O Ports	2 x USB 10Gbps ports (1 x TypeA + 1 x USB TypeC ®) 3 x USB 5Gbps ports (3 x TypeA) 3 x USB 2.0 ports (3 x TypeA) 1 x DisplayPort 1 x HDMI ™ port 1 x WiFi module 1 x Realtek 2.5Gb Ethernet port 3 x Audio jacks 1 x BIOS FlashBack ™ button
Internal I/O Connectors	Fan and Cooling Related 1 x 4pin CPU Fan header 1 x 4pin CPU OPT Fan header 1 x 4pin AIO Pump header 4 x 4pin Chassis Fan headers Power Related 1 x 24pin Main Power connector 1 x 8pin +12V CPU Power connector 1 x 4pin +12V CPU Power connector Storage Related 3 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 20Gbps connector (supports USB TypeC ® ) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports Miscellaneous 3 x Addressable RGB Gen 2 headers 1 x Clear CMOS header 1 x Chassis Intrusion header 1 x COM Port header 1 x Front Panel Audio header (F_AUDIO) 1 x 101 pin Front Panel System header
Special Features	ASUS TUF PROTECTION DIGI+ VRM ( Digital power design with DrMOS) ESD Guards TUF LANGuard Overvoltage protection SafeSlot Stainlesssteel back I/O ASUS QDesign M.2 QLatch PCIe Slot QRelease QAntenna QDashboard QDIMM QLED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) QSlot ASUS Thermal Solution Flexible M.2 heatsink VRM heatsink design ASUS EZ DIY BIOS FlashBack ™ button BIOS FlashBack ™ LED ProCool Premounted I/O shield SafeDIMM Aura Sync Addressable RGB Gen 2 headers
Software Features	ASUS Exclusive Software Armoury Crate Aura Creator Aura Sync Fan Xpert 4 Power Saving ASUS AI Advisor ASUS DriverHub ASUS GlideX TurboV Core TUF GAMING CPUZ DTS Audio Processing Adobe Creative Cloud (Free Trial) Norton 360 for Gamers (60 Days Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS ASUS EZ DIY ASUS CrashFree BIOS 3 ASUS EZ Flash 3 ASUS UEFI BIOS EZ Mode ASUS MyHotkey
BIOS	256 Mb Flash ROM, UEFI AMI BIOS
Manageability	WOL by PME, PXE
Accessories	Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x ASUS WiFi QAntenna 1 x TUF Gaming sticker 1 x M.2 rubber package 2 x Screw packages for M.2 SSD Documentation 1 x Quick start guide
Operating System	Windows 11, Windows 10 64bit
Form Factor	ATX Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm)
