SPECIFICATIONS:
VIDEO INPUT | |
Interfaces |
1 x HDMI Type A Female (Black) |
Impedance |
100 Ω |
Max. Distance |
Max 1.5m at 7680x4320 @ 60Hz (4:2:0) |
VIDEO OUTPUT | |
Interfaces |
2 x HDMI Type A Female (Black) |
Impedance |
100 Ω |
Max. Distance |
Max 1.5m at 7680x4320 @ 60Hz (4:2:0) |
VIDEO | |
Max. Data Rate |
48 Gbps |
Compliance |
HDMI (3D, Deep Color, 8K) |
Max. Resolution |
7680x4320 @ 60Hz (4:2:0) |
AUDIO | |
Input |
1 x HDMI Type A Female (Black) |
Output |
2 x HDMI Type A Female (Black) |
CONNECTORS | |
Power |
1 x USB-C (5V/1A) |
CABLE LENGTH | |
USB Cable |
1 x USB Type-C to Type-A (1m) |
LEDS | |
LED Indicator |
2 x Port Indicator (Orange) |
Power |
2 (Orange, Bottom Side) |
ENVIRONMENTAL | |
Operating Temperature |
0-40 °C |
Storage Temperature |
-20 - 60 °C |
Humidity |
0 - 80% RH, Non-Condensing |
PHYSICAL PROPERTIES | |
Housing |
PC |
Weight |
0.03 kg ( 0.07 lb ) |
Dimensions (L x W x H) |
6.10 x 5.65 x 1.52 cm |
Note |
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
OTHERS |
|
Package Contents |
1x 2-Port 8K HDMI Splitter 1x USB power cable (Type-C to Type-A) (1 m) |
