SPECIFICATIONS:

GENERAL
TDP (W)	280
Color option	Black
Overall dimensions without mounting material (L x W x H), (mm)	145 x 136 x 168
Total weight (kg)	1.34
Socket compatibility Intel	1700 / 1200 / 1150 / 1151 / 1155
Socket compatibility AMD	AM5 / AM4
Overall noise level (dB(A)) @ 50/75/100% (rpm)	11 / 19.5 / 25.8
Number of fans	2
Lighting connector	â
HEATSINK
Dimensions (L x W x H), (mm)	120 x 136 x 168
Fin material	Aluminum
Surface treatment	Ceramic coating
Base material	Copper
CPU contact surface	CNC machined
Heatpipe number / Diameter (mm)	7 / 6
FAN
Fan model	Silent Wings
Fan dimensions (mm)	135 x 135 x 25
Speed @ 100% PWM /12V (rpm)	1500 / 2000
Bearing technology	Fluid Dynamic Bearing
Motor technology	6-pole fan motor
Rated Voltage (V)	12
Input current (A)	0.40
Input power (W)	4.8
Connector	4-pin PWM
Cable length (mm)	120 / 80
Lifespan (h / 25Â°C)	300,000
Y-Cable	â
ACCESSORIES
Thermal grease (Type)	Included
Mounting set	Intel & AMD
Y-Cable	â
User manual languages	CN, DE, EN, ES, FR, JP, PL, RU, TW
SAFETY CERTIFICATION
Approvals	CE, UKCA, UL, TÃV
ENVIRONMENTAL DIRECTIVES
RoHS	â
WEEE	â
Triman	â
