SPECIFICATIONS:
DISPLAY |
|
Brightness (ANSI lumens) |
500 |
Native Resolution |
720p (1280x720) |
Native Aspect Ratio |
16:9 |
Contrast Ratio (FOFO) |
100,000:1 |
Display Color |
30-bit (1.07 billion colors) |
Light Source |
LED |
Light Source Life |
a. Normal 20000 hrs, b. ECO 30000 hrs |
OPTICAL |
|
Throw Ratio |
1.3 |
Zoom Ratio |
Fixed |
Lens |
Fixed |
Projection Offset (Full-Height) |
100% |
Keystone Adjustment |
1D, (Auto) Vertical ± 40 degrees |
PICTURE |
|
Rec. 709 Coverage |
98% |
Picture Modes |
Bright, Cinema, Sport, Vivid TV |
COMPATIBILITY |
|
Input Lag |
33.4 ms (1080P 60Hz) |
Resolution Support |
VGA(640 x 480) to Full HD(1920 x 1080) |
Horizontal Frequency |
15K~102KHz |
Vertical Scan Rate |
23~85Hz |
I/O INTERFACE |
|
HDMI in |
(x1), HDMI-1 (1.4a/HDCP1.4) |
USB Type A |
USB Type A-1 (2.0/Power Supply1.5A/Reader) |
USB Type C |
USB Type C-1 (2.0/DisplayPort Alt Mode/Reader) |
AUDIO |
|
Speaker |
(x2), 2W |
ENVIRONMENT |
|
Operating Temperature |
0~40 |
Power Supply |
AC 100 to 240 V, 50/60 Hz |
Typical Power Consumption (110V) |
42W@100 ~ 240VAC |
Stand-by Power Consumption |
<0.5W |
Acoustic Noise (Typ./Eco.)(dB) |
31/29 dBA |
ACCESSORIES |
|
Wireless USB dongle |
WDR02U |
Carry Bag |
(Standard) |
Remote Control w/ Battery |
RCI014 |
Power Cord (by region) |
x1 (1.8M) |
Quick Start Guide |
(x1) 12L |
Warranty Card (by region) |
Yes |
ONSCREEN DISPLAY |
|
Launcher |
Smart Home |
SMART SYSTEM |
|
Built-in OS |
Yes, Android 6.0 |
Bluetooth |
Yes, Bluetooth 4.0 |
Wireless Projection |
AirPlay, Google Cast |
DIMENSION AND WEIGHT |
|
Dimensions (WxHxD) (mm) |
139mm x 144mm x 139mm |
Net Weight (kg) |
1.6kg |
PROJECTION SYSTEM |
|
Projection System |
DLP |
