Key Features:
- Amplifier Class: Digital (D)
- Led Indicator: Power/Protection
- Power Input Terminal Size: 4ga
- Fuse Size: 3x40A
- Remote Level Control: YES
- Thermal Protection: YES
- Over-Load Protection: NO
- DC Output Protection: YES
- Short Circuit Output Protection: YES
- Voltage Input Protection: YES
- 3200W
- 4 Channel Stereo Class-D
- Amplifier 2ohm stable
- Nickel-plated RCA input connectors 3200W peak 4-channel Class D amp with 750W bridged output
- Adjustable Gain, Low-Pass, Hi-Pass and Crossover Switch selector
Specifications:
-
Power
- Total Watts (Peak): 3200W
- RMS Power @ 4 ohm: 280W x 4
- RMS Power @ 2 ohm: 400W x 4
- RMS Power @ 4 ohm Bridge: 750W x 2
-
Audio
- Frequency Response: 20Hz-45KHz
- Signal to Noise Ratio: >93dB
- Total Harmonic Distortion (THD): 0.12%
- Low Level Input Range: 0.25-6V
- High Level Input: Yes
- Selectable X-Over: LPF/FLAT/HPF
- X-Over Filter Range: 35-250Hz
- Bass Boost Range: 0-12dB
- Bass Boost Frequency: Fixed @ 45Hz
- Infrasonic Filter: 10-50Hz
