SPECIFICATIONS:
|
BASIC SPECS |
|
|
Functions |
|
|
Printer Type |
Laser Printer |
|
Product Dimensions (Width X Depth X Height) |
373 mm × 388 mm × 289 mm |
|
Weight |
10.7 kg |
|
Print Speed |
Up to 50 (A4) / Up to 52 (Letter) ppm |
|
Paper Type |
Plain Paper, Letterhead, Coloured Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env.Thin, Env.Thick |
|
Paper Size |
A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper), COM-10, DL, C5, Monarch |
|
Maximum Paper Capacity |
Up to 1,660 sheets of 80 gsm Plain Paper |
|
|
|
|
Resolution |
Up to 1200 x 1200 dpi |
|
2-Sided (Duplex) - Printing Paper Type |
Plain Paper, Letterhead, Coloured Paper, Thin Paper, Recycled Paper |
|
2-Sided (Duplex) - Paper Size |
A4, Letter, Legal, Folio, Mexico Legal, India Legal (A4 size paper are supported only in some countries.) |
|
PAPER HANDLING |
|
|
Tray #1 - Maximum Paper Weight |
60 to 163 gsm (16 to 43 lb) |
|
Tray #1 - Maximum Paper Capacity |
Up to 520 sheets of 80 gsm plain paper |
|
Tray #1 - Paper Size |
A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper) |
|
Tray #2 - Maximum Paper Weight |
60 to 120 gsm (16 to 32 lb) |
|
Tray #2 - Maximum Paper Capacity |
LT-5505: Up to 250 sheets of 80 gsm plain paper LT-6505: Up to 520 sheets of 80 gsm plain paper |
|
Multi-purpose Tray - Maximum Paper Weight |
60 to 230 gsm (16 to 60 lb) |
|
Multi-purpose Tray - Paper Size |
to 8.5") Length: 127 to 355.6 mm (5" to 14") Envelope: COM-10, DL, C5, Monarch |
|
Multi-purpose Tray - Maximum Paper Capacity |
Up to 100 sheets of 80 gsm plain paper |
|
Paper Output |
Up to 150 sheets of 80 gsm plain paper (face-down delivery to the face-down output paper tray) 1 sheet (face up delivery to the face up output tray) |
|
CONNECTIVITY |
|
|
WiFi Direct |
Yes |
|
Connectivity |
Hi-SpeedUSB2.0, IEEE 802.11b/g/n (Infrastructure Mode), IEEE 802.11a/g/n (Wi-Fi Direct) |
|
NETWORK |
|
|
Wireless Network Security |
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES) *Wi-Fi Direct supports WPA2-PSK (AES) only. |
|
Wireless Setup Support Utility - WPS |
Yes |
|
DISPLAY & MEMORY |
|
|
Display Type |
1 Line LCD (16 characters) |
|
Memory Capacity |
256 MB |
|
OPERATION |
|
|
Power Source |
220 - 240 V AC 50/60 Hz |
|
Power Consumption - Printing |
Approximately 710 W |
|
Power Consumption - Ready |
Approximately 31 W |
|
Power Consumption - Sleep |
Approximately 5.5 W |
|
Power Consumption - Power Off |
Approximately 0.05 W |
|
Noise Level |
54 dB (A) |
|
SUPPORTED OPERATING SYSTEMS |
|
|
Supported OS |
Windows 10 Server 2012 / 2012R2 / 2016 / 2019 |
