Celestion T5762: 1" 20W HF Driver 8OHM

Description

The Celestion 1" 20W HF Driver 8OHM exit lightweight and compact ferrite magnet compression driver with 1.4" copper clad aluminium voice coil.

20Wrms power handling (AES standard) and 106dB sensitivity.

One piece PETP diaphragm and surround Finite Element Analysis (FEA) techniques used to optimise both magnetic and acoustic design.

Suitable for 2-way and 3-way systems.

Key Features:

Power rating 20Wrms
Sensitivity 106dB
Recommended min. crossover (12dB/oct) 2200Hz
Voice coil diameter 35mm/1.4in
Voice coil material Copper clad aluminium
Diaphragm material PETP film
Overall width 90mm/3.54in
Overall depth 52mm/2.05in
Unit weight 1kg/2.2lb
Fitting Flange (4 x M6 holes on 76mm/3in PCD)
Throat exit 25mm/1in

What's in the box:

1 x Celestion 1" 20W HF Driver 8OHM

Product specifications

Speaker Type: PA Speakers
Product Depth (mm): 90.0
Product Width (mm): 90.0
Product Height (mm): 80.0
Product Weight (kg): 1.0
Contains button battery: No
Accessory type: Speakers
Manufacturer's warranty: 12 Months

CELESTION

Celestion T5762: 1" 20W HF Driver 8OHM

Model: 28/CDX1-1445 SKU: 10012937

AUDIO

Price:

$96.8

Key features

Compact and lightweight design for easy handling
High power handling and exceptional sensitivity
Optimized magnetic and acoustic design for superior performance
