Celestion T5916: 1" 12W HF Driver 8 Ohm

Description

Very lightweight, low-profile ferrite magnet compression driver.

12Wrms (AES standard) power handling and 106dB sensitivity, 1500-20,000Hz frequency range.

Finite Element Analysis (FEA) techniques used to optimise both magnetic and acoustic design.

Ideal for entry-level two-way and three-way sound reinforcement cabinets.

Key Features:

Power rating 12Wrms
Nominal impedance 8O
Frequency range 1500-20,000Hz
Sensitivity 106dB
Recommended min. crossover (12dB/oct) 2200Hz
Voice coil diameter 25mm/1.0in
Voice coil material Copper clad aluminium
Magnet type Ferrite
Diaphragm material PETP film
Surround material PETP film

What's in the box:

1 x Celestion 1" 12W HF Driver 8 Ohm

Product specifications

Speaker Type: PA Speakers
Product Depth (mm): 90.0
Product Width (mm): 90.0
Product Height (mm): 60.0
Product Weight (kg): 0.5
Contains button battery: No
Accessory type: Speakers
Manufacturer's warranty: 12 Months

CELESTION

Celestion T5916: 1" 12W HF Driver 8 Ohm

Model: 28/CDX1-1070 SKU: 10012900

AUDIO

Price:

$60.76

Key features

Extremely light and compact ferrite magnet compression driver
Handles 12W power with 106dB sensitivity, covering 1500-20,000Hz range
Utilizes FEA methods for top magnetic and acoustic optimization
