Product Number	MLX-D36M-A25SZ-L1
Colour	Black
CPU Socket (Intel)	LGA 1851 / 1700 / 1200 / 1150 / 1151 / 1155 / 1156
CPU Socket (AMD)	AM5 / AM4
Radiator Material	Aluminium
Radiator Dimensions (mm)	394 x 119.2 x 27
Pump Dimensions (mm)	92.5 x 87 x 39
Pump Profiles	Addressable Gen2 RGB
Pump Speed (RPM)	3400 ± 300
Pump MTTF (Hours)	>210,000
Pump Noise Level (dBA)	25 (Max)
Pump Rated Voltage	12 VDC
Pump Power Consumption	3.84 W
Pump Connector	3-Pin ARGB + 4-Pin PWM
Tube Length (mm)	400
Fan Dimensions (L x W x H mm)	361 x 122 x 26.5
Fan Profile	Addressable Gen 2 RGB
Fan Quantity	1 PC
Fan Speed (RPM)	690 ~ 2500 ± 15%
Fan Airflow	322.8 m³/h (190 CFM)
Fan Air Pressure	3.61 mmH2O
Fan MTTF (Hours)	>160,000
Fan Noise Level (dBA)	38.5
Fan Bearing Type	Loop Dynamic Bearing
Fan Connector	7-Pin PWM + ARGB
Fan Rated Voltage	12 VDC
Fan Rated Current	0.5 A
Fan Safety Current	0.8 A
Fan Power Consumption	6 W
LCD Dimensions (mm)	85.0 x 79.2 x 18.7
LCD Connector	USB Type-C to Motherboard 9‑pin
LCD Screen Size	Diameter 53.3 mm
LCD Resolution	480 x 480 px
LCD Luminance	300 cd/m²
LCD Refresh Rate	60 Hz
LCD Rated Voltage	5 VDC
LCD Rated Current	0.3 A
LCD Safety Current	0.5 A
LCD Power Consumption	1.5 W
Warranty	6 years
Radiator Size	360
Cooler Type	Liquid Cooler
Series	MasterLiquid
