Product Number	MLX-D36M-A25SZ-V1
Colour	Black
CPU Socket (Intel)	Intel® LGA 1851 / 1700 / 1200 / 1150 / 1151 / 1155 / 1156
CPU Socket (AMD)	AMD® AM5 / AM4
Radiator Material	Aluminium
Radiator Dimensions	394 x 119.2 x 27 mm
Pump Dimensions	92.5 x 87 x 39 mm
Pump Profiles	Addressable Gen2 RGB
Pump Speed	3400 ± 300 RPM
Pump MTTF	>210,000 Hours
Pump Noise Level	25 dBA (Max)
Pump Rated Voltage	12 VDC
Pump Power Consumption	3.84 W
Pump Connector	3-Pin ARGB + 4-Pin PWM
Tube Length	400 mm
Fan Dimensions (L x W x H)	361 x 122 x 26.5 mm
Fan Profile	Addressable Gen 2 RGB
Fan Quantity	1 PC
Fan Speed	690 ~ 2500 RPM ± 15%
Fan Airflow	322.8 m³/h (190 CFM)
Fan Air Pressure	3.61 mmH2O
Fan MTTF	>160,000 Hours
Fan Noise Level	38.5 dB(A)
Fan Bearing Type	Loop Dynamic Bearing
Fan Connector	7-Pin PWM + ARGB
Fan Rated Voltage	12 VDC
Fan Rated Current	0.5 A
Fan Safety Current	0.8 A
Power Consumption	6 W
VRM Fan Dimensions	85.0 x 79.2 x 16 mm
VRM Fan Connector	USB Type-C to Motherboard 9pin
VRM Fan Resolution	28 x 26 px (556 px)
VRM Fan Orientation	Software-MasterCtrl adjustable
VRM Fan Rated Voltage	5 VDC
VRM Fan Rated Current	0.5 A
VRM Fan Safety Current	5.0 A
VRM Fan Power Consumption	2 W
Warranty	6 years
Radiator Size	360
Cooler Type	Liquid Cooler
Series	MasterLiquid
