Specification	Details
Product Number	MLX-D24M-A18P2-R1
Exterior Colour	Black
CPU Socket	LGA2066, LGA2011-v3, LGA2011, LGA1700*, LGA1200, LGA1151, LGA1150, LGA1155, LGA1156, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1
Radiator Material	Aluminium
Radiator Dimensions	277 x 119.6 x 27.2 mm
Pump Dimensions	81.4 x 76 x 57.8 mm
Pump MTTF	70,000 Hours
Pump Noise Level	< 10 dBA
Pump Connector	3-Pin
Pump Rated Voltage	12 VDC
Pump Power Consumption	2.36 W
Fan Dimensions (L x W x H)	120 x 120 x 25 mm
Fan Quantity	2 PCS
Fan LED Type	Addressable Gen 2 RGB
Fan Speed	650-1800 RPM ± 10%
Fan Airflow	47.2 (Max)
Fan Noise Level	6 - 30 dBA
Fan Pressure	1.60 mmH₂O (Max)
Fan Life Expectancy	160,000 Hours
Fan Power Connector	4-Pin (PWM)
Fan Rated Voltage	12VDC
Fan Rated Current	0.25A
RAM Clearance	N/A
Warranty	3 Years
Series	MasterLiquid
Cooler Type	Liquid Cooler
Radiator Size	240mm
Note	*New models will include an LGA1700 bracket. If your cooler is purchased after September 1st 2021 and does not include a bracket, contact your reseller or Cooler Master ANZ on Facebook to claim one.
