The Corsair 2800X RS-R ARGB Micro-ATX PC Case houses high-performance hardware within a dual-chamber steel chassis fitted with front and side tempered glass panels. Built for clean aesthetic layouts, it combines pre-installed reverse-rotor ARGB fans with extensive radiator mounting options.
Unobstructed panoramic view with pre-installed reverse-rotor ARGB cooling
The 2800X RS-R features a dual-chamber layout that isolates heat-generating components like the GPU and CPU from the power supply and drive storage. Tempered glass front and left side panels create a clean visual window into the main chamber, giving you a clear view of internal hardware and custom lighting.
To deliver efficient intake airflow without obstructing your view, Corsair equips the chassis with three pre-installed RS120-R ARGB reverse-rotor fans. Because the fan blades are inverted, the rear frame structure faces away from the glass interior, delivering direct air across core components while keeping the lit fan face fully visible. In total, the frame accommodates up to 10x 120mm fans across top, side, bottom, and rear mounts for complete thermal customisation.
Hidden cable builds with reverse-connector motherboard support
To support modern cable-management standards, the chassis accommodates both standard and reverse-connector Micro-ATX and Mini-ITX motherboards. Reverse-connector motherboards allow main power, SATA, and front-panel connections to plug into the back of the PCB, keeping wiring completely out of the main visual chamber.
A generous 24 mm of cable routing space behind the motherboard tray provides ample room to organize main power harnesses neatly. Integrated dust filters on the top, bottom, and side panels prevent dust buildup over time, keeping your internal hardware clean.
Generous clearance for full-length GPUs and up to 360mm radiators
Despite a compact Micro-ATX footprint measuring 447 mm high, 436.4 mm long, and 232 mm wide, the 2800X RS-R accommodates large hardware without thermal or physical restrictions.
- Graphics Card Clearance: Fits GPUs up to 410 mm in length across 4 horizontal expansion slots.
- CPU Cooler Clearance: Accommodates air coolers up to 170 mm in height.
- Power Supply Clearance: Accepts standard ATX power supplies up to 200 mm in length in the rear chamber.
- Liquid Cooling Support: Fits top radiators up to 360mm (or 280mm), side radiators up to 240mm, and a 120mm rear radiator.
20Gbps front-panel USB-C and integrated GPU reinforcement
The top front I/O panel provides modern high-speed connectivity. A USB 3.2 Gen 2x2 Type-C port supports throughput speeds up to 20Gbps, complemented by a USB 3.2 Gen 1 Type-A port and a 3.5mm audio combo jack for headsets.
To support heavy multi-slot graphics cards and prevent sag over time, the case features an integrated GPU anti-sag arm. This adjustable bracket keeps long graphics cards level without needing external accessories or additional brackets.
Practical drive mounts backed by a two-year warranty
Storage installation remains straightforward and hidden in the secondary chamber. The chassis provides internal drive bays for one 3.5-inch hard drive and two 2.5-inch solid-state drives, offering flexible capacity without blocking intake airflow. Corsair backs the 2800X RS-R ARGB Micro-ATX PC Case with a 2-year warranty.
