The Corsair iCUE LINK TITAN 280 RX RGB pairs a 280mm aluminum radiator with a FlowDrive 3-phase pump motor to deliver high-capacity CPU cooling across modern Intel LGA 1851/1700 and AMD AM5/AM4 sockets. Built around a copper cold plate and pre-applied thermal compound, this all-in-one liquid cooler combines high static pressure airflow with Corsair's single-cable iCUE LINK interface.

FlowDrive 3-phase pump engine and copper thermal transfer

At the center of the cooling loop is Corsair's FlowDrive pump engine, utilizing a 3-phase motor that maintains consistent fluid motion while minimising operational noise. Heat from the processor is transferred directly through a high-conductivity copper cold plate pre-coated with CORSAIR XTM70 thermal paste, eliminating air gaps and ensuring optimal thermal contact right out of the box.

Coolant circulates through 400mm black sleeved low-permeation rubber tubing into an aluminum radiator measuring 317mm x 140mm x 27mm. The low-permeation tubing construction reduces coolant loss over time, keeping the closed-loop system maintenance-free throughout its service life.

High-static-pressure RX140 RGB magnetic dome fans

The radiator is cooled by two 140mm x 25mm iCUE LINK RX140 RGB PWM fans. Driven by Magnetic Dome bearings, these fans reduce mechanical friction to ensure quiet operation and extended lifespan across their 300 to 1,700 RPM operating range.

• Airflow delivery: Scales from 17.9 CFM at minimum speed up to 94.7 CFM at maximum output for heavy workloads.
• Static pressure focus: Generates between 0.15 and 3.75 mm-H2O, forcing air effectively through dense radiator fin stacks.
• Acoustic control: Operates between 10 dBA at idle and 36 dBA under full load, giving users granular control over noise curves.

Streamlined build architecture with iCUE LINK

System assembly is simplified using the iCUE LINK ecosystem, which consolidates RGB lighting signals and PWM fan control through a single unified connection protocol. Instead of routing separate 4-pin fan cables and 3-pin addressable RGB cables for every fan and pump head, iCUE LINK allows components to daisy-chain together. This drastically reduces cable clutter behind the motherboard tray and accelerates system assembly.

Broad socket support backed by a six-year warranty

The cooler comes with mounting hardware for modern mainstream and high-performance desktop platforms. Its bracket system ensures correct mounting pressure across current and upcoming CPU socket designs.
