Host Interface

USB 3.2 Gen 2 10Gbps

HDMI Output

1 x HDMI, up to 4K at 60Hz

USB-A Data Ports

2 x USB-A 5Gbps; backward compatible with USB 2.0 and USB 1.1

USB-A Auxiliary Port

1 x USB-A 480Mbps

Ethernet

1 x RJ45 Gigabit Ethernet, up to 1000Mbps

Card Readers

1 x SD and 1 x microSD (TF)

Card Standard

SD 3.0 / UHS-I; theoretical speed up to 104MB/s in SDR104 mode

Power Input

1 x USB-C PD 3.0 input, up to 100W

USB-A Output Current

Up to 900mA per USB 5Gbps port; up to 500mA for the USB 480Mbps port, subject to host power availability

Material

Aluminium + ABS

Colour

Space Grey

Chipset

Genesys Logic

Product Dimensions

100 x 48 x 15mm

Integrated Cable Length

15cm

Cable Jacket

Black PVC

Cable Shielding

Aluminium foil

System Support

Compatible Windows and macOS systems

Driver

No additional driver required on supported systems

HDMI Requirement

Host USB-C port must support DisplayPort Alt Mode; available resolution depends on the host, operating system, display and cable

Packaging Dimensions

135 x 82 x 17mm
