SPECIFICATIONS:
Product Dimensions |
125Ã144Ã159 mm(LÃWÃH) |
Heatsink Dimensions |
125Ã115Ã153 mm(LÃWÃH) |
Net Weight |
1386 g |
Heatpipe |
Ã6 mmÃ6 pcs |
Fan Dimensions |
120Ã120Ã25 mm(LÃWÃH) |
Fan Speed |
2000 ±10% RPM(max) |
Fan Airflow |
57.76 CFM |
Fan Air Pressure |
2.78 mmAq |
Fan Noise |
¤28.87 dB(A) |
Fan Connector |
4-pin PWM |
Bearing Type |
Hydro Bearing |
Fan Rated Voltage |
12 VDC |
Fan Rated Current |
0.19 A |
Fan Power Consumption |
2.28 W |
Display Module Rated Current |
0.13 A ±10% |
Display Module Rated Voltage |
5 VDC |
Display Module Power Consumption |
0.65 W |
Display Area |
29x39 mm |
Application For |
Intel LGA1851/1700/1200/115X AMD AM5/AM4 |
