SPECIFICATIONS:
|
Product Dimensions |
481×240×516mm(L×W×H) |
|
Net Weight |
9.8Kg |
|
Materials |
ABS+SPCC+Tempered Glass |
|
Motherboard Support |
Mini-ITX / Micro-ATX / ATX ATX(Rear Connector)/Micro-ATX(Rear Connector) |
|
Front I/O Ports |
USB3.0×2、Gen2 Type-C x1、Audio/Mic×1 |
|
3.5" Drive Bays |
1 |
|
2.5" Drive Bays |
2+1 |
|
Expansion Slots |
8 Slots |
|
Pre-Installed Fans |
None |
|
Fan Support |
Front:NA Top:3×120 / 3×140mm Side:3×120 / 3×140mm PSU Shrouded :3×120 / 3×140mm Rear: 1×120 / 1×140mm |
|
Radiator Support |
Front: NA Top: 120/140/240/280/360/420mm Side: 120/140/240/280mm Bottom: 120/240/360mm |
|
CPU Cooler Height Limit |
182mm |
|
GPU Length Limit |
450mm |
|
Power Supply Type |
ATX PS2（maximum length: 180mm） |
