SPECIFICATIONS:
Net Weight |
1768 g |
Radiator Dimensions |
402Ã120Ã27 mm(LÃWÃH) |
Radiator Material |
Aluminum |
Tube length |
410 mm |
Pump Dimensions |
131Ã89Ã58 mm(LÃWÃH) |
Pump Speed |
3400 ±10% RPM (MAX) |
Pump Connector |
4-pin PWM |
Pump Rated Voltage |
12 VDC |
Pump Rated Current |
0.29 A |
Pump Power Consumption |
3.48 W |
Fan Dimensions |
120Ã120Ã25 mm(LÃWÃH) |
Fan Speed |
500~2500 RPM ±10% |
Fan Airflow |
75.33 CFM |
Fan Air Pressure |
2.41 mmAq |
Fan Noise |
¤33.66 dB(A) |
Fan Connector |
4-pin PWM |
Bearing Type |
Hydro Bearing |
Fan Rated Voltage |
12 VDC |
Fan Rated Current |
0.28 A |
Fan Power Consumption |
3.36 W |
LED Type |
Addressable RGB LED |
LED Connector |
3-pin(+5V-D-G) |
LED Rated Voltage |
5 VDC |
LED Power Consumption |
1.65 Wï¼PUMPï¼/ 5.1 Wï¼FANÃ3ï¼ |
Display Specifications |
4.5 inch 480*854 TFT LCD |
Application For |
Intel LGA1851/1700/1200/1151/1150/1155 AMD AM5/AM4 |
