SPECIFICATIONS:
Net Weight |
1847 g |
Radiator Dimensions |
402Ã120Ã27 mm(LÃWÃH) |
Radiator Material |
Aluminum |
Tube length |
410 mm |
Pump Dimensions |
93Ã77Ã66 mm(LÃWÃH) |
Pump Speed |
3400 RPM ±10% |
Pump Connector |
3-pin |
Pump Rated Voltage |
12 VDC |
Pump Rated Current |
0.35 A |
Pump Power Consumption |
4.2 W |
Fan Dimensions |
120Ã120Ã25 mm(LÃWÃH) |
Fan Speed |
500~2150 RPM ±10% |
Fan Airflow |
72.45 CFM |
Fan Air Pressure |
4.32 mmAq |
Fan Noise |
¤36.49 dB(A) |
Fan Connector |
4-pin PWM |
Bearing Type |
Fluid Dynamic Bearing |
Fan Rated Voltage |
12 VDC |
Fan Rated Current |
0.3 A |
Fan Power Consumption |
3.6 W |
LED Type |
Addressable RGB LED |
LED Connector |
3-pin(+5V-D-G) |
LED Rated Voltage |
5 VDC |
LED Power Consumption |
2.45 Wï¼PUMPï¼ |
Display Specifications |
2.83 inch 480Ã640 TFT LCD |
Application For |
Intel LGA1700/1200/1151/1150/1155 AMD AM5/AM4 |
