Interface

PCIe 3.0x4, NVMe1.3 interface

Form Factor

M.2 2280

Total Capacity

500GB

External DDR Cache

N/A

Sequential Read speed

Up to 2300 MB/s

Sequential Write speed

Up to 1500 MB/s

Random Read IOPS

Up to 60K

Random Write IOPS

Up to 240K

Dimension

22 x 2.3 x 80 mm

Mean time between failure (MTBF)

1.5 million hours

Power Consumption (Active)

Average R : 2670mW

Average W : 3200mW

Power Consumption (Idle)

Idle : 30mW

L1.2

Temperature (Operating)

0°C to 70°C

Temperature (Storage)

-40°C to 85°C

Note

• Test system configuration: configuration may vary by models, we will choose the latest platform for verification.

• Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.

• Speeds based on internal testing. Actual performance may vary.

• 1GB = 1 billion bytes. Actual useable capacity may vary.
