SPECIFICATIONS:
|
ESSENTIALS |
|
|
Product Collection |
Intel Core Ultra Processors (Series 2) |
|
Code Name |
Products formerly Arrow Lake |
|
Vertical Segment |
Desktop |
|
Processor Number |
265F |
|
Overall Peak TOPS (Int8) |
25 |
|
CPU SPECIFICATIONS |
|
|
Total Cores |
20 |
|
# of Performance-cores |
8 |
|
# of Efficient-cores |
12 |
|
Total Threads |
20 |
|
Max Turbo Frequency |
5.3 GHz |
|
Intel Turbo Boost Max Technology 3.0 Frequency |
5.3 GHz |
|
Performance-core Max Turbo Frequency |
5.2 GHz |
|
Efficient-core Max Turbo Frequency |
4.6 GHz |
|
Performance-core Base Frequency |
2.4 GHz |
|
Efficient-core Base Frequency |
1.8 GHz |
|
Cache |
30 MB Intel Smart Cache |
|
Total L2 Cache |
36 MB |
|
Processor Base Power |
65 W |
|
Maximum Turbo Power |
182 W |
|
Intel Deep Learning Boost (Intel DL Boost) on CPU |
Yes |
|
AI Software Frameworks Supported by CPU |
OpenVINO , WindowsML, DirectML, ONNX RT, WebNN |
|
CPU Lithography |
TSMC N3B |
|
MEMORY SPECIFICATIONS |
|
|
Max Memory Size (dependent on memory type) |
192 GB |
|
Memory Types |
Up to DDR5 6400 MT/s |
|
Max # of Memory Channels |
2 |
|
ECC Memory Supported |
Yes |
|
NPU SPECIFICATIONS |
|
|
NPU Name |
Intel AI Boost |
|
NPU Peak TOPS (Int8) |
13 |
|
Sparsity Support |
Yes |
|
Windows Studio Effects Support |
Yes |
|
AI Software Frameworks Supported by NPU |
OpenVINO , WindowsML, DirectML, ONNX RT, WebNN |
|
EXPANSION OPTIONS |
|
|
Direct Media Interface (DMI) Revision |
4 |
|
Max # of DMI Lanes |
8 |
|
Intel Thunderbolt 4 |
Yes |
|
Scalability |
1S Only |
|
PCI Express Revision |
5.0 and 4.0 |
|
PCI Express Configurations |
Up to 1x16+2x4, 2x8+2x4, 1x8+4x4 |
|
Max # of PCI Express Lanes |
24 |
|
PACKAGE SPECIFICATIONS |
|
|
Sockets Supported |
FCLGA1851 |
|
Thermal Solution Specification |
PCG 2022C |
|
Max Operating Temperature |
105 C |
|
ADVANCED TECHNOLOGIES |
|
|
Intel Volume Management Device (VMD) |
Yes |
|
Intel Gaussian & Neural Accelerator |
3.5 |
|
Intel Thread Director |
Yes |
|
Intel Speed Shift Technology |
Yes |
|
Intel Turbo Boost Max Technology 3.0 |
Yes |
|
Intel Turbo Boost Technology |
2.0 |
|
Intel 64 |
Yes |
|
Instruction Set |
64-bit |
|
Instruction Set Extensions |
Intel SSE4.1, Intel SSE4.2, Intel AVX2 |
|
Idle States |
Yes |
|
Enhanced Intel SpeedStep Technology |
Yes |
|
Thermal Monitoring Technologies |
Yes |
|
SECURITY & RELIABILITY |
|
|
Intel vPro Eligibility |
Intel vPro Enterprise |
|
Intel Threat Detection Technology (TDT) |
Yes |
|
Intel Active Management Technology (AMT) |
Yes |
|
Intel Standard Manageability (ISM) |
Yes |
|
Intel Remote Platform Erase (RPE) |
Yes |
|
Intel One-Click Recovery |
Yes |
|
Intel Control-Flow Enforcement Technology |
Yes |
|
Intel Total Memory Encryption - Multi Key |
Yes |
|
Intel AES New Instructions |
Yes |
|
Secure Key |
Yes |
|
Intel Trusted Execution Technology |
Yes |
|
Execute Disable Bit |
Yes |
|
Intel OS Guard |
Yes |
|
Intel Boot Guard |
Yes |
|
Mode-based Execute Control (MBEC) |
Yes |
|
Intel Stable IT Platform Program (SIPP) |
Yes |
|
Intel Virtualization Technology with Redirect Protection (VT-rp) |
Yes |
|
Intel Virtualization Technology (VT-x) |
Yes |
|
Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
|
Intel VT-x with Extended Page Tables (EPT) |
Yes |
