Form Factor

M.2 2280

Interface

PCIe 4.0 x4 NVMe

Capacity

500GB

* Some of the listed capacity on a Flash storage device is used for formatting and other functions and thus is not available for data storage. As such, the actual available capacity for data storage is less than what is listed on the products.

Sequential Read/Write

5,000/3,000MB/s

* Based on “out-of-box performance” using a PCIe 4.0 motherboard. Speed may vary due to host hardware, software, and usage.

NAND

3D

Endurance (Total Bytes Written)

160TB

* Total Bytes Written (TBW) is derived from the JEDEC Client Workload (JESD219A).

Storage Temperature

-40°C~85°C

Operating Temperature

0°C~70°C

Dimensions

22mm x 80mm x 2.3mm

Weight

7g (All capacities)

Vibration Non-operating

20G (10-1000Hz)

MTBF

2,000,000 hours
