Efficiency

80 PLUS Gold / Cybenetics Platinum / PPLP Gold

DC Output Cable

Full-Modular

Dimensions

(D)150 mm X (W)86 mm X (H)150 mm

Color

White

Material

SECC

PFC

Active PFC, PF > 0.90 under full load @ 115Vac, 60Hz

Input Rating

100-240Vac 15-8A,

50-60Hz

Max. DC Output

1000W

Combined +12V

1000W

Combined +3.3V & +5V

100W

Fan Spec

135mm FDB Fan

Fan RPM

1600rpm

Fanless Mode

YES

Noise Level

36.21dBA @ 30 „ƒ, 100cm away from micphone to PSU

MTBF

100,000 hrs minimum 25 „ƒ/75% Load

Protection

OCP，OVP，OTP，OOP，SCP，UVP，NLP，SIP

Working Temperature

0-40 „ƒ
