SPECIFICATIONS:
|
Efficiency rating |
80 PLUS Gold (up to 90%) |
|
Modular |
Yes (full modular) |
|
Fan size |
120 mm |
|
Fan bearing |
Fluid Dynamic Bearing |
|
Dimensions (DXWXH) |
140 x 150 x 86 mm |
|
PFC type |
Active PFC |
|
Input voltage range |
100~240 VAC |
|
Power watt |
750W |
|
Power excursion |
1500W (*up to 200% of the PSU's rated power for 100μs) |
|
Input frequency range |
47-63Hz |
|
Protection |
OCP / OVP / OPP / OTP / SCP / UVP |
|
ATX (24 PIN) |
1 |
|
EPS (4+4 PIN) |
2 |
|
PCI-E 5.0 (16 PIN) |
1 (450W) |
|
PCI-E (6+2 PIN) |
3 |
|
SATA (15 PIN) |
8 |
|
MOLEX (4 PIN) |
4 |
|
FDD (4 PIN) |
1 |
