SPECIFICATIONS:

Size	92x92x25 mm
Mounting hole spacing	82,5x82,5 mm
Connector & pin-configuration	3-pin
Cable length	20cm + 30cm NA-EC1 extension cable
Bearing	SSO2
Blade geometry	A-Series with Flow Acceleration Channels
Frame technology	AAO (Advanced Acoustic Optimisation)
Rotational speed (+/- 10%)	1600 RPM
Rotational speed with L.N.A. (+/- 10%)	1250 RPM
Rotational Speed with U.L.N.A. (+/- 10%)	1050 RPM
Airflow	64,6 m ³/h
Airflow with L.N.A.	51,1 m ³/h
Airflow with U.L.N.A.	42,9 m ³/h
Acoustical noise	17,1 dB(A)
Acoustical noise with L.N.A.	11,6 dB(A)
Acoustical noise with U.L.N.A.	8,4 dB(A)
Static pressure	1,62 mm H O
Static pressure with L.N.A.	1,04 mm H O
Static pressure with U.L.N.A.	0,71 mm H O
Input power (typical)	0,396 W
Input power (max.)	0,84 W
Input current (typical)	0,033 A
Max. input current	0,07 A
Operating voltage	12 V
MTTF	> 150.000 h
Scope of delivery	Low-Noise Adaptor (L.N.A.) Ultra-Low-Noise Adaptor (U.L.N.A.) 3:4-Pin Adaptor 30cm Extension Cable 4 Vibration-Compensators 4 Fan Screws
