SPECIFICATIONS:
|
Size |
120x120x25 mm |
|
Mounting hole spacing |
105x105 mm |
|
Connector & pin-configuration |
4-pin PWM |
|
Bearing |
SSO2 |
|
Blade geometry |
Heptaperf™ |
|
Frame technology |
Focused Flow™ |
|
Rotational speed (+/- 10%) |
1500 RPM |
|
Min. rotational speed @ 20% PWM (+/-20%) |
300 RPM |
|
Airflow |
93,4 m³/h |
|
Acoustical noise |
22,4 dB(A) |
|
Static pressure |
2,61 mm H₂O |
|
Input power (typical) |
0,65 W |
|
Input power (max.) |
0,75 W |
|
Input current (typical) |
0,13 A |
|
Max. input current |
0,15 A |
|
Operating voltage |
5 V |
|
MTTF |
> 150.000 h |
|
Scope of delivery |
30cm extension cable NA-AV1 anti-vibration mounts USB power adaptor cable OmniJoin adaptor set Fan screws |
|
Notes |
Being a 5V fan, the NF-F12 5V PWM cannot be run at 12V and will be damaged when used with typical 12V power sources such as PC motherboard fan headers. |
