Socket compatibility

Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4

(Current socket compatibility applies to all coolers purchased since Q3 2021.)

Height (without fan)

115 mm

Width (without fan)

140 mm

Depth (without fan)

163 mm

Height (with fan)

115 / 142 mm

Width (with fan)

140 mm

Depth (with fan)

163 mm

Weight (with fan)

1015 g

Material

Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating

NSPR

119

Max. TDP

see NSPR

Fan compatibility

140x140x25mm (with square frame)

Scope of delivery

1x NF-A14 PWM premium fan

NA-RC7 Low-Noise Adaptor (L.N.A.)

Fan clips for second fan

NT-H1 high-grade thermal compound

SecuFirm2 „¢ Mounting Kit

Noctua Metal Case-Badge

FAN SPECIFICATION

Model

1x Noctua NF-A14 PWM

Bearing

SSO2

Max. rotational speed (+/- 10%)

1500 RPM

Max. rotational speed with L.N.A. (+/- 10%)

1200 RPM

Min. rotational speed @ 20% PWM (+/-20%)

300 RPM

Max. airflow

140,2 m ³/h

Max. airflow with L.N.A.

115,5 m ³/h

Max. acoustical noise

24,6 dB(A)

Max. acoustical noise with L.N.A.

19,2 dB(A)

Input power (max.)

1,56 W

Voltage range

12 V

MTTF

> 150.000 h
