SPECIFICATIONS:

Socket compatibility	AM5, AM4, LGA1700, LGA1851, LGA1954, LGA1156, LGA1155, LGA1150, LGA1151, LGA1200
Total height	168 mm
Fan configuration	2x 140x140x25mm (round)
NSPR	228
Colour	Black
Fan Size (Form factor)	140 x 140 x 25 mm (round)
Speed range	0 1500 rpm
Airflow (max.)	155.6 m ³/h (91.58 CFM)
Acoustical noise (max.)	24.8 dB(A)
Static pressure (max.)	2.56 mm H O
Rated voltage	12 V
Connector	4-pin
Colour	Black
Height with fan(s)	168 mm
Height without fan(s)	168 mm
Width with fan(s)	150 mm
Width without fan(s)	150 mm
Depth with fan(s)	152 mm
Depth without fan(s)	127 mm
Weight with fan(s)	1525 g
Weight without fan(s)	1180 g
Material: heatsink base	Copper, nickel plated
Material: heatsink fins	Aluminium, nickel plated
Material: heatpipes	Copper, nickel plated
Interface heatpipes/heatsink fins	Soldered
Base convexity	Standard
Colour	Black
Number of heatpipes	8
Heatpipe diameter	6 mm
Fin count	58
Mounting hole pitch	78 mm
Rack unit compatibility	5U
Base size	44.6 x 51.6 mm
NSPR	228
