SPECIFICATIONS:

COOLER SPECIFICATION
Socket compatibility	Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4 (Current socket compatibility applies to all coolers purchased since Q2 2022. For older coolers, please refer to this chart.)
Height (without fan)	160 mm
Width (without fan)	150 mm
Depth (without fan)	135 mm
Weight (without fan)	980 g
Height (with fan)	165 mm
Width (with fan)	150 mm
Depth (with fan)	161 mm
Weight (with fan)	1320 g
Material	Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
NSPR	183
Max. TDP	see NSPR
Fan compatibility	140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25
Scope of delivery	2x NF-A15 PWM premium fan 2x NA-RC7 Low-Noise Adaptor (L.N.A) NA-YC1 4-pin PWM splitter cable NT-H1 high-grade thermal compound SecuFirm2™ mounting kit Noctua metal case-badge
FAN SPECIFICATION
Model	2x Noctua NF-A15 PWM
Bearing	SSO2
Max. rotational speed (+/- 10%)	1500 RPM
Max. rotational speed with L.N.A. (+/- 10%)	1200 RPM
Min. rotational speed @ 20% PWM (+/-20%)	300 RPM
Max. airflow	140,2 m³/h
Max. airflow with L.N.A.	115,5 m³/h
Max. acoustical noise	24,6 dB(A)
Max. acoustical noise with L.N.A.	19,2 dB(A)
Voltage range	12 V
MTTF	> 150.000 h
