SPECIFICATIONS:
|
COOLER SPECIFICATION |
|
|
Socket compatibility |
Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4 |
|
Height (without fan) |
77 mm |
|
Width (without fan) |
128 mm |
|
Depth (without fan) |
131 mm |
|
Weight (without fan) |
410 g |
|
Height (with fan) |
77 mm |
|
Width (with fan) |
128 mm |
|
Depth (with fan) |
131 mm |
|
Weight (with fan) |
520 g |
|
Material |
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating |
|
NSPR |
100 |
|
Max. TDP |
see NSPR |
|
Fan compatibility |
120x120x15 & 120x120x25 |
|
Scope of delivery |
NF-A12x15 PWM premium fan NA-RC7 Low-Noise Adaptor (L.N.A.) NT-H2 high-grade thermal compound SecuFirm2™ mounting kit Noctua metal case-badge |
|
FAN SPECIFICATION |
|
|
Model |
1x Noctua NF-A12x15 PWM |
|
Bearing |
SSO2 |
|
Max. rotational speed (+/- 10%) |
1850 RPM |
|
Max. rotational speed with L.N.A. (+/- 10%) |
1400 RPM |
|
Min. rotational speed @ 20% PWM (+/-20%) |
450 RPM |
|
Max. airflow |
94,2 m³/h |
|
Max. airflow with L.N.A. |
70,8 m³/h |
|
Max. acoustical noise |
23,9 dB(A) |
|
Max. acoustical noise with L.N.A. |
16,8 dB(A) |
|
Input power (max.) |
1,56 W |
|
Voltage range |
12 V |
|
MTTF |
> 150.000 h |
