Socket compatibility

Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4

(Current socket compatibility applies to all coolers purchased since Q4 2021. For older coolers, please refer to this chart.)

Height (without fan)

158 mm

Width (without fan)

125 mm

Depth (without fan)

58 mm

Weight (without fan)

760 g

Height (with fan)

158 mm

Width (with fan)

125 mm

Depth (with fan)

112 mm

Weight (with fan)

1220 g

Material

Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating

NSPR

169

Max. TDP

see NSPR

Fan compatibility

120x120x25

Scope of delivery

2x NF-A12x25 PWM 120mm fan

2x NA-RC14 Low-Noise Adaptor (L.N.A.)

NA-YC1 4-pin PWM splitter cable

SecuFirm2â„¢ mounting kit

NT-H1 thermal compound

Noctua Metal Case-Badge

FAN SPECIFICATION

Model

Noctua NF-A12x25 PWM

Bearing

SSO2

Max. rotational speed (+/- 10%)

2000 RPM

Max. rotational speed with L.N.A. (+/- 10%)

1700 RPM

Min. rotational speed @ 20% PWM (+/-20%)

450 RPM

Max. airflow

102,1 m³/h

Max. airflow with L.N.A.

84,5 m³/h

Max. acoustical noise

22,6 dB(A)

Max. acoustical noise with L.N.A.

18,8 dB(A)

Voltage range

12 V

MTTF

> 150.000 h
