Cable specs

24-pin ATX power:600 mm, Nylon sleeving

4+4-pin CPU power:700 mm, Nylon sleeving

8-Pin CPU Power Cable:700mm, Nylon sleeving

6+2-pin PCIe power:650 + 150 mm, Nylon sleeving

16-Pin (12+4) 12VHPWR PCIe Cable:650mm, Nylon sleeving

SATA power:500 + 150 mm

Peripherals:500 + 150 mm

AC input rating

100 - 240Vac:14A-7A 50Hz-60Hz

DC output rating

+3.3V and +5V:22A (120W)

+12V:100A (1200W)

-12V:0.3A (3.6W)

5Vsb:3A (15W)

Total:1200W

Operation

PF Correction:Active @0.96

MTBF:100,000 hours

Temperature:0 - 50 °C (derating from 100% to 80% from 40 °C to 50 °C)

Energy efficiency

Rating:80 Plus Gold

20% loading:87.5% @115Vac

50% loading:90.5% @115Vac

100% loading:87.5% @115Vac

Fan specs

Dimensions:135 x 135 x 25 mm

Speed:0-2300 ± 10% RPM

Airflow:93.02 CFM (Tpy.)

Noise:44.5 dBA max

Bearing:Fluid Dynamic Bearing (FDB)

General

Dimensions:150 x 150 x 86mm

Material(s):Steel, PCB and Plastic

Compliance Standard:ATX12V v3.0 / EPS12V v2.92

Regulation & Certification:cTUV-SUDus / CUL (UL60950/62368-1) / TUV / (EN60950/62368-1) / CB/ (IEC 950/62368-1) / CCC / CEC /BSMI / RCM / EAC / CE / LVD / UKCA
