SPECIFICATIONS:

GPU	AMD Radeon ¢ RX 9070 XT Graphics Card AMD RDNA ¢ 4 Architecture
Engine Clock	Boost Clock: Up to 3060 MHz Game Clock: Up to 2520MHz * Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads. * Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.
Stream Processors	4096
Compute Units	64 CUs (3rd Gen RT + 2nd Gen AI Accelerators)
Infinity Cache	64MB
Ray Accelerators	64
AI Accelerator	128
Memory Size/Bus	16GB/256 bit GDDR6
Memory Clock	20 Gbps Effective
Displays	Maximum 4 Displays
Resolution	HDMI ®: 7680Ã4320 DisplayPort ¢ 2.1a: 7680Ã4320
Interface	PCI-Express 5.0 x16
Output	2x HDMI ® 2x DisplayPort ¢ 2.1a
BIOS Support	UEFI
Game Index	4K
Sapphire Features	Quick Connect MagniPlate STEALTH Hidden Power Cable 12V-2x6(H++) External Power Connector (3x8-pin power adapter is also included if your PC's Power Supply Unit does not have 12V-2x6) Honeywell PTM7950 Thermal Interface Material (TIM) AeroCurve Fan Blade Free Flow FrameDefense Integrated Cooling Module Cold Rolled Steel Frame Tri-X Cooling Technology High TG Copper PCB Optimized Composite Heatpipes Metal Backplate ARGB Light Bar Fan Quick Connect Two-Ball Bearing Fans Premium 16-Phase Digital Power Design Fuse Protection Intelligent Fan Control Precision Fan Control TriXX Supported Performance vs. Efficiency Quicksets Glow! Fan Check TriXX Boost External RGB LED MB Synchronization
Accessories Bundled	L-Shape Support Bracket 3pin 5V ARGB Cable Magnetic Backplate 12V-2x6(H++) to PCI Express 3x8-pin power adapter
AMD Features	AMD RDNA ¢ 4 Architecture 64 Compute Units (3rd Gen RT + 2nd Gen AI Accelerators) AMD HYPR-RX with AFMF 2 AMD FidelityFX ¢ Super Resolution 4 with AI Upscaling DisplayPort ¢ 2.1a AMD Radiance Display ¢ Engine AMD Fluid Motion Frames 2 technology AMD Radeon ¢ Anti-Lag 2 technology AV1 Encode/Decode AMD FidelityFX ¢ technologies Microsoft ® DirectX ® 12 Ultimate AMD Noise Suppression AMD Freesync ¢ technology 16 GB of GDDR6 on 256-bit Memory Bus AMD smart technologies AMD Software: Adrenalin Edition ¢ application
Cooler Type	Tri-X Cooling AeroCurve Fan Blade Free Flow Integrated Cooling Module High TG Copper PCB Optimized Composite Heatpipes Two-Ball Bearing
Form Factor	3.2 slot, ATX Dimension: 330.8(L)X 128.5(W)X 65.68 (H)mm
Power Consumption	330W Typical Board Power
OS	Linux ®, Windows ® 10, and Windows 11. 64-bit operating system required
System Requirement	Minimum 750 Watt Power Supply 12V-2x6(H++) Power Connector (3x8-pin power adapter is also included if your PC's Power Supply Unit does not have 12V-2x6) PCI Express ® based PC is required with one X16 lane graphics slot available on the motherboard. Minimum 8GB of system memory. 16GB recommended.
