Max. DC Output

750W

Power density

415W per liter

Combined +3.3V & +5V

110W

Combined +12V

744W

Input Voltage

90 ~ 264 Vrms

Input Frequency Range

47Hz ~ 63Hz

PFC

Active PFC (PF>0.9 at full load)

Efficiency

87% ~ 90% (at 20% ~ 100% loading)

MTBF

100,000 hours

Operating temperature

0 ~ 40 °C

Protection

Over current protection

Over power protection

Over voltage protection

Short circuit protection

Over temperature protection

Connectors

1 x 24 / 20-Pin motherboard connector (600mm)

2 x 8 / 4-Pin EPS / ATX 12V connector ("750mm" x 2)

2 x 8 / 6-Pin PCIe connector ("650mm" x 2)

2 x 8 / 6-Pin PCIe connector ("650mm / 150mm")

8 x SATA connector ("600mm / 150mm / 150mm / 150mm" x 2)

6 x 4-Pin Peripheral connector + 2 x 4-Pin Floppy adapter connector ("600mm / 150mm / 150mm / 150mm" x 2)

Cooling System

Silent 120mm FDB fan

Noise Level

18 dBA minimum

Certification

80 PLUS Gold

Form factor

ATX (PS2)

Dimension

150mm (W) x 86mm (H) x 140mm (D)

Weight

1.44 kg
