Color

Black

Material

Plastic front panel, steel body

Transfer rate

Up to 12Gbit/s (dependent on drive speed)

Application

5.25" drive bay x 3**

Cooling system

80mm fan x 1

Power connector

SATA 15-Pin x 1, Molex 4-Pin x 1

Drive support

5 x 2.5" / 3.5" SAS*/SATA SSD or HDD

Host interface

7-Pin SATA connector x 5 or SAS* primary channel connection

Drive security

Metal key lock design

Number of key

2

LED indicator

HDD Power LED: Green

HDD Access: Blue blinking

Dimension

146mm (W) x 126mm (H) x 206mm (D)

Net weight

1.8 kg

Notes

* Your system must have SAS controller if you want to use SAS HDD.

* Hard drive capacity and RAID support is dependent on SAS or SATA controller used.

** FS305-E is designed for maximum space utilization. In order to fit five 3.5" drive bays into the space of three 5.25" bays, the sides are designed flat with no cutouts to fit between 5.25" bays with protruding lip or brackets. Therefore, please make sure your case has 5.25" bays that are also flat on the inside with no protrusions. If not, please consider using FS303 or FS304 instead.
