Case Type

Full Tower

Dimension (H x W x D)

550 x 248 x 548 mm

(21.7 x 9.8 x 21.6 inch)

Panel

Steel + TG

Color

White

Material

SPCC

Cooling System

140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 4

Drive Bays

5 x 3.5 € , 1 x 2.5 € or 6 x 2.5 €

Expansion Slots

8

Motherboards

6.7 € x 6.7 € (Mini ITX), 9.6 € x 9.6 € (Micro ATX), 12 € x 9.6 € (ATX) ,

12 € x 13 € (E-ATX), SSI-CEB, SSI-EEB

Hidden-Connector Motherboard

9.6 € x 9.6 € (Micro ATX), 12 € x 9.6 € (ATX)

I/O Port

USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1

PSU

Standard PS2 PSU (optional)

Fan Support

Front:

4 x 120mm ,3x 120mm , 2x 120mm , 1x 120mm

3 x 140mm , 2x 140mm , 1x 140mm

Top

3 x 120mm , 2x 120mm , 1x 120mm

3 x 140mm , 2x 140mm , 1x 140mm

Rear:

1 x 120mm , 1 x 140mm

Right:

3 x 120mm , 2x 120mm , 1x 120mm

2 x 140mm , 1x 140mm

Power Cover:

3 x 120mm , 2x 120mm , 1x 120mm

Radiator Support

Front (AIO):

1 x 360mm, 1 x 240mm, 1 x 120mm

1 x 420mm, 1 x 280mm, 1 x 140mm

Top (AIO):

1 x 360mm, 1 x 240mm, 1 x 120mm

1 x 420mm, 1 x 280mm, 1 x 140mm

Rear(AIO):

1 x 120mm , 1 x 140mm

Clearance

CPU cooler height limitation: 185mm(Max)

VGA length limitation:460mm(Max)

PSU length limitation: 200mm (Max)
