Series

CTE

Case Type

Mid Tower

Dimension (H x W x D)

558.5 x 270 x 513mm

(21.99 x 10.63 x 20.2 inch)

Net Weight

14.5 kg / 31.97 lbs.

Panel

4mm Tempered Glass x 3

Color

Snow

Material

SPCC

Cooling System

3 x 3.5”, 1 x 2.5” or 2 x 3.5”, 2 x 2.5”

Expansion Slots

7

Motherboards

6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),

12” x 9.6” (ATX), 12” x 10.5” (E-ATX)

I/O Port

USB 3.0 x 2, Type-c x1, HD Audio x 1

PSU

Standard PS2 PSU (optional)

Fan Support

Top:

2 x 120mm, 1 x 120mm

Right (M/B Side):

3 x 120mm, 2 x 120mm, 1 x 120mm

3 x 140mm ,2x 140mm, 1 x 140mm

Bottom:

3 x 120mm, 2 x 120mm, 1 x 120mm

3 x 140mm ,2x 140mm, 1 x 140mm

Radiator Support

Top:

1 x 240mm, 1 x 120mm

Right (M/B Side):

1 x 360mm, 1 x 240mm, 1 x 120mm

1 x 420mm, 1 x 280mm, 1 x 140mm

Bottom (DIY only):

1 x 360mm, 1 x 240mm, 1 x 120mm

1 x 420mm, 1 x 280mm, 1 x 140mm

Clearance

CPU cooler max height: 166mm

VGA max length: 415mm (with radiator)

443.8mm (without radiator)

PSU max length: 220mm
