System Compatibility

System Compatibility : Windows 10 / 11

Fan Spec

Dimension : 120 x 120 x 25 mm

Fan Speed : PWM 500~2000 R.P.M

Rated Voltage : 12V/5V

Rated Current : 0.27 A & 0.72 A (one fan)

Power Input : 3.24 W & 3.6 W (one fan)

Air Flow : Standard Fan Blade : 57.11 CFM (one fan)

Air Flow : Reverse Fan Blade : 56.26 CFM (one fan)

Static Pressure : Standard Fan Blade : 2.39 mm-H2O (one fan)

Static Pressure : Reverse Fan Blade : 2.02 mm-H2O (one fan)

Noise Level : Standard Fan Blade : 30.6 dB-A (one fan)

Noise Level : Reverse Fan Blade : 32.5 dB-A (one fan)

Power Spec

Rated Voltage : 5V

Rated Current : 1.2A

Power Input : 6W

Display Type : 3.95 € TFT-LCD x 4

Display Resolution : 720x720 (RGB) px

Pump Spec

Motor Speed : PWM 1500~3300 RPM

Rated Voltage : 12V

Rated Current : 0.43A

Power Input : 5.16W

Fan Speed: 3500 RPM

Rated Voltage: 12V

Rated Current: 0.06A

Power Input: 0.72W

Noise Level: 20 dB-A

Air Flow: 6.8 CFM

Static Pressure: 1.5 mm-H2O

Tube Spec

Length : 460mm

Material : Rubber

Water Block

Material : Copper

Compatibility

CPU Socket :

Intel LGA 2066/2011-3/2011/1851/1700/1200/1156/1155/1151/1150 AMD AM5/AM4/AM3+/AM3/AM2+/AM2/FM2/FM1
