Model

SPD-650AH2CLB

Max. Output capacity

650W

Color

Black

Dimension ( W / H / D )

150mm(W)x86mm(H)x140mm(D)

PFC (power factor correction)

Active PFC

Power good signal

100-150 msec

Hold up time

> 17msec

Input current

15A-6A

Input frequency range

50Hz/60Hz

Input voltage

100-240V～

Operating temperature

5°C to + 45°C

Operating humidity

20% to 85%, non-condensing

Storage temperature

-40°C to + 55°C

Storage humidity

10% to 95%, non-condensing

Cooling system

12cm FDB Fan

Efficiency

Meet 80 PLUS® Bronze at 115Vac input.

MTBF

100,000 hrs minimum

Safety approval

CE/UKCA/LVD/UKCA/FCC/ICES/TUV/CB/cTUVus/BSMI/CCC

PCI-E 6+2PIN

4

PCIE 12+4PIN

1(300w)

Protection

OCP/OVP/UVP/OPP/OTP/SCP
