SPECIFICATIONS:
Fan dimension |
140 x 140 x 25 mm |
Interface |
2510-4 PIN PWM, 5V ARGB header-3PIN |
Fan started voltage |
9.0 V |
Fan rated voltage |
12 V & 5V |
Rated current |
12 V - 0.32 A , 5 V 0.72 A (one fan) |
Power input |
12 V 3.84 W , 5 V 3.6 W (one fan) |
Fan speed |
PWM 500 ~ 2000 R.P.M |
Max. Air pressure |
Standard Fan Blade : 3.17 mm-H2O (one fan) Reverse Fan Blade : 2.73 mm-H2O (one fan) |
Max air flow |
Standard Fan Blade : 81.6 CFM (one fan) Reverse Fan Blade : 79.3 CFM (one fan) |
Noise level |
Standard Fan Blade : 34.5 dB-A (one fan) Reverse Fan Blade : 38.8 dB-A (one fan) |
Bearing type |
Hydraulic Bearing |
Life expectation |
40,000 hrs,25 |
Included items |
Fan Frames x 3 Standard Fan Blade x 3 (Pre-installed) Reverse Fan Blade x 3 Cable x 3 |
