SPECIFICATIONS:
|
Watts |
1050W |
|
Model |
TTP-1050AH2FKG |
|
Max. Output capacity |
1050W |
|
Color |
Black |
|
Dimension ( W / H / D ) |
150mm(W)x86mm(H)x140mm(D) |
|
PFC (Power Factor Correction) |
Active PFC |
|
Power good signal |
100-250 msec |
|
Hold up time |
> 17msec |
|
Input current |
15A Max. |
|
Input frequency range |
50Hz - 60Hz |
|
Input voltage |
100 - 240Vac |
|
Operating temperature |
0°C to + 45°C |
|
Operating humidity |
5% to 85%,non-condensing |
|
Storage temperature |
-40°C to + 70°C |
|
Storage humidity |
5% to 95%, non-condensing |
|
Cooling system |
12cm FDB Fan |
|
Efficiency |
Meet 80 PLUS® Gold at 115Vac input. |
|
MTBF |
100,000 hrs minimum |
|
Safety approval |
CE/FCC/UKCA/ICES/LVD/TUV/cTUVus/CB/CCC/BSMI |
|
PCI-E 6+2PIN |
5 |
|
PCIE 12+4PIN |
1(600W) |
