SPECIFICATIONS:
|
Model |
TPD-750AH2FXG-3 |
|
Watts |
750W |
|
Max Output Capacity |
750W |
|
Color |
Snow |
|
Dimensions |
150mm(W)x86mm(H)x140mm(D) |
|
PFC (Power Factor Correction) |
Active PFC |
|
Power Good Signal |
100-250 msec |
|
Hold Up Time |
> 17msec at 80% load |
|
Input Current |
10A Max. |
|
Input Frequency Range |
50Hz-60Hz |
|
Input Voltage |
100-240V～ |
|
Operating Temperature |
0°C to + 40°C |
|
Operating Humidity |
5% to 85% |
|
Storage Temperature |
-40°C to + 70°C |
|
Storage Humidity |
5% to 95% |
|
Cooling System |
12cm Hydraulic bearing fan |
|
Efficiency |
Meet 80 PLUS® Gold at 115Vac input. |
|
MTBF |
100 |
|
Safety Approval |
CE/UKCA/ICES/TUV/LVD/RCM/CB/FCC/cTUVus/BSMI/CCC/BIS/S-MARK |
|
PCI-E 6+2PIN |
4 |
|
PCI-E 12+4PIN |
1(600W) |
|
Protection |
OVP/UVP/OCP/OPP/OTP/SCP |
