SPECIFICATIONS:

Box dimensions	330 x 425 x 340 mm (13 x 16.7 x 13.4")
Box weight	16 kg (35.3 lb)
Cable length	305 m (1,000 ft)
Cable color	Black
Cable type	CAT5e, shielded
UV resistance	ASTM G 151/154
Ethernet support	Up to 1 Gbps
Conductor wire gauge	24 AWG
Conductor	Solid bare copper
Conductor diameter	0.500 ± 0.005 mm
Insulation type	Solid polyethylene
Insulation thickness	Avg. 0.295 mm Min. 0.29 mm
Insulation diameter	1.16 ± 0.02 mm
Separation (Polyester wrapping)	Thick: 0.025 mm Extent: 20 mm
Anti-crosstalk divider	LDPE: 4.2*0.3 mm
Cable shield (Aluminum foil)	Thick: 0.060 mm Extent: 20 mm
ESD drain wire	0.4 TC
Rip cord	Yes
Secondary cable shield (Braid)	1680.16AA Density: 95%
Jacket material	Polyethylene
Jacket thickness	Avg. 0.52 mm Min. 0.46 mm
Jacket outer diameter	6.8 ± 0.30 mm
Jacket color	Black
Storage temperature	-30 to 75 ° C (-22 to 167 ° F)
Installation temperature	-20 to 60 ° C (-4 to 140 ° F)
Ambient operating temperature	-40 to 80 ° C (-40 to 176 ° F)
Standards	ANSI/TIA-568-C.2 (2009) ISO/IEC 11801 (Edition 2.2)
