SPECIFICATIONS:
USB Upstream Ports |
USB 3.0 AF x2 (Connect to PC1 and PC2) |
USB Downstream Ports |
USB 3.0 AF x4 (Connect USB peripherals) |
Monitor Input |
HDMI 2.1 x2, DP 1.4 x2 (Connect to PC1 and PC2) |
Monitor Output |
HDMI 2.1 x1, DP 1.4 x1 (Connect to displays) |
Power Input |
USB-C, DC 5V (power input only, no data transfer function) |
USB Max Bandwidth |
SuperSpeed 5Gbps |
Video Max Bandwidth |
up to 48Gbps |
Max Video Resolution |
8K@60Hz (7680Ã4320), 4K@120Hz (3840Ã2160), 2K@165Hz (2560Ã1440), 1080p@240Hz (1920Ã1080) |
Max Cable Length for Input/Output |
¤3m for 8K@60Hz, ¤5m for 4K@60Hz |
Operating Temperature Range |
5 °C to 45 °C |
Operating Humidity Range |
5 to 90%RH (no Condensation) |
Dimension (L x W x H) |
14.4 x 6.6 x 4.75cm |
Weight |
300g |
Operating System Support |
Windows, MacOS, Linux, Chrome OS |
